Multi Functional Power Transformer Demagnetization and DC Resistance Integrated Tester

Multi Functional Power Transformer Demagnetization and DC Resistance Integrated Tester

Overview Main technical indicators:★The degaussing function has all the parameters of 105 and 105A ★Steady current volta;
Send inquiry
  • Overview
  • Product Description
  • Company Profile
Overview
Basic Info.
Model NO. XHXC205
Trademark XZH TEST
Origin Shaanxi
Product Description

Main technical indicators:★The degaussing function has all the parameters of 105 and 105A ★Steady current voltage: 20A/10A/5A/1A/100mA five gears ★Measurement range: 100mA:1Ω-200Ω 1A: 100mΩ-20Ω 5A: 2mΩ-4Ω 10A: 500μΩ-2Ω 20A: 200μΩ-1Ω ★Accuracy: ± (0.2 reading + 2 words) Resolution: 0.1uΩ ★Environmental conditions: Temperature: -10-50ºC Humidity: ≤85%RH ★Working power supply: AC 220V±10% 50Hz±1Hz

Multi Functional Power Transformer Demagnetization and DC Resistance Integrated Tester


Multi Functional Power Transformer Demagnetization and DC Resistance Integrated Tester


Multi Functional Power Transformer Demagnetization and DC Resistance Integrated Tester



Multi Functional Power Transformer Demagnetization and DC Resistance Integrated Tester



Multi Functional Power Transformer Demagnetization and DC Resistance Integrated Tester



Product Description


XHXC205 Power Transformer Degaussing Machine It integrates the power transformer mutual inductor degaussing instrument and the power transformer DC resistance tester. It has both the function of conventional DC resistance testing and all the functions of the degaussing instrument.

Company Profile
